HYG1009A01011A


metal base pcb

1lay ALU white metal base pcb



Production process:


Cutting1.jpgChemical&Physical Laborato.jpgInner Dry Film Imaging.jpgInner layer etch.jpg
Cutting
laboratoryDry FilmInner Etching
Auto Drill Bit Sharpener.jpgDrilling (Auto Drilling machine).jpgPTH & Surface Copper Measu.jpgPanel plating.jpg
Auto Drill Bit SharpenerDrillingPTHPanel Plating
HASL Line (Lead and Lead.jpgENIG ThicknessSolder Mask.jpgAuto E-test Machine.jpg
HASL Lead FreeImmersion Gold
Solder MaskE-test
Routing.jpgFQC.jpgAOI Test.jpgInspection Machine.jpg
ProfileFQCAOI SacningInpection Machine
Final Audi.jpgpacking.jpg


Final AudiPacking

 Specification:

CodeHYG1009A01011ACustomer PN


Layer1Blind/Buried ViaNO

Base MaterialALU
Unit Size(mm)27.5000
X20.0000
Board thickness1.7mmPanle Size(mm)145.5000X108.0000
Min hole2.5mmPcs/Panle5X4
Total Holes64Copper OZ(finish)1OZBase Cu/
W/S(mil)/Min Hole Copper Thickness/

Outline FinishCNC+V-CUT
Finish thickness tolerance+/-10%

Contour tolerance+/-0.15mmSurface Finishing
HASL Lead Free


X-out/Solder MaskWhite

Special request/
SilkscreenBlack
